Home > products > Continuous Ambient Air Quality Monitoring System
CAAQMS-91
The CAAQMS-91 is designed for Continuous Monitoring of Environment parameter such as Particulate Matters, Gases, Temperature, Humidity and Atmospheric Pressure in the air. System has facility to incorporate with Meteorological parameter
measurements.
Immediate measurement of the concentration of Gases and dusts present in a specific location both urban and industrial. Gases and Particulate measuring equipment in air pollution monitoring networks. Gases and Particulate measurements in construction or moving materials area. Measuring the concentrations of the particles inhaled by a person during a day. Mapping an area with respect to the concentration of the atmospheric particulate.
The system provides immediate measurement of the concentration of gases & dusts present in a specific location both urban and industrial for evaluating the environmental safety degree in a working area. Can also be use on moving vehicles such as mobile laboratories, trains etc.,
Controlling & checking the forecast modelling of the pollutant’s concentration in the atmosphere, Measuring the concentrations of the pollutants inhaled by a person during a day, Mapping an area with respect to the concentration of the atmospheric pollutants.
Features...
The system is designed for Continuous Monitoring Applications to be installed open to the sky at the prescribed monitoring location.
The Microprocessor & PLC based technology helps the system to perform accurately & efficiently.
An instantaneous reading of the level of pollutants & dust are displayed at the location of system installed.
It offers a facility for interfacing to a computer for Real Time & Date Remote Data Acquisition & Monitoring.
On screen, continuous display of concentration with real date & time in tabulation with over range identification and graphical representation of each measurement.
High resolution readings at low cost.
Continuous Monitoring System.
Data Logging of instantaneous.
Stored reading can be viewed, printed or downloaded to a computer for long term storage. Real date & time maintained.
Technical Specifications...
Parameters...
| Parameter Measurement | Measuring Principle | Parameters | Range | |
| Dust Measurement | β-ray attenuation | PM10 PM2.5 | 1-1000 μg/m3 1-1000 μg/m3 | |
| Gas Measurement | UV Fluorescence, Chemiluminescence, NDIR Technology, Gas Sensing Electrochemical, TDLAS, Photo-ionization detector (PID) | SO2 NO2 CO HCL BTEX | 0-200 ppb 0-2000 ppb 0-1000 ppm 0-1000 ppm 0-1000 ppm |
